Introduction to PsychoPy#

Important prerequisites#

In order to get the best and most helpful experience out of this session, there are two important prerequisites everyone should have. If you have any problems concerning this, please just let one of the instructors know.

I - solid understanding of python#

II - working PsychoPy installation#

You should have downloaded the standalone version specific for your OS from https://www.psychopy.org/download.html (it should automatically suggest the fitting version via the big blue button) and subsequently installed it.

You should be able to see the PsychoPy application in your Applications/Programs, click on it to open it!

Computational environments#

While we could set up and use a computational environment as discussed in the school prerequisites and RDM session, we will use the standalone version of PsychoPy for this session.

The reasons are outlined below, but in short, the manual installation tends to result in some differences between operating systems concerning drivers, etc. and we unfortunately don’t have time to address these potential problems during the session. However, please note and remember that the manual installation usually works perfectly fine and you can utilize either in your local setup.

Outline#

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

Running experiments (using Python)#

Did some of you already acquired data/run experiments.
If so what did you use and what was your experience like?

Experiment software and builders#

One argument that is routinely brought up goes something like “Clearly open source can’t match the performance of proprietary software.”. While performance is definitely an important aspect, generalizing that open source software is generally worse, isn’t very accurate and also not very scientific. How about having a precise look at it and compare different software and settings?

That’s exactly what the The timing mega-study: comparing a range of experiment generators, both lab-based and online did:

  • compared prominently used software across OS, local & online

  • PsychoPy showed performance comparable to proprietary software

  • prominent differences between OS:

    • ubuntu > windows > macOS

  • also prominent differences between browsers

  • online versions less precise, independent of software but PsychoPy overall great performance

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

Introduction to PsychoPy#

basic overview#

PsychoPy resources#

PsychoPy website

PsychoPy documentation

PsychoPy discourse forum

https://www.psychopy.org/

https://psychopy.org/documentation.html

https://discourse.psychopy.org/

RDM - Experiments#

Starting new experiments follows the same guidelines as starting new projects in general:

  • create and store everything in a dedicated place on your machine

  • use the (standalone version of) PsychoPy specific for your OS

  • document everything or at least as much as possible

  • test and save things in very short intervals, basically after every change

PsychoPy components#

The standalone version of PsychoPy comes with three distinct windows and respective functionalities.

PsychoPy Experiment files#

As mentioned before, we will save and store everything in a dedicated place on our machines. In PsychoPy experiments that are created/managed via the Builder are saved as .psyexp files, so let’s check this. After you opened PsychoPy, ie the Builder, you can do either save it via File -> Save as or the little 💾 icons. In both cases you should select the code/experiment directory we created.

What’s one of the first things we always have to do when utilizing python?

That’s right: thinking about modules/functions we need.

PsychoPy modules#

psychopy.core

various basic functions, including timing & experiment termination

psychopy.gui

creation/management of dialog boxes allowing user input

psychopy.event

handling of keyboard/mouse/other input from user

psychopy.visual/sound

presentation of stimuli of various types (e.g. images, sounds, etc.)

psychopy.data

handling of condition parameters, response registration, trial order, etc.

many more …

we unfortunately can’t check out due to time constraints

Question for y’all

Which one do we most likely need?

A general experiment workflow#

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

basic working principles#

After this brief overview of PsychoPy and its parts, we will explore some of it basic working principles, situated along the above outlined experiment workflow.

Dialog box(es) to get user input#

Many experiments start with a GUI dialog box that allow users/participant to input certain information, for example participant id, session, group, data storage path, etc. .

We can implement this crucial aspect via the psychopy.gui module with the respective being accessible via the ⚙️ icon in the top menu bar.

It will open the Experiment Properties window through which we can set a variety of important experiment characteristics, including Experiment info which will become our dialog box.

Let’s add a few fields to the dialog box

How about participant ID, session, age, handedness, etc. ?

That’s actually all we need to test our GUI dialog box!

In order to do that, we need to run/execute our experiment. This is achieved via clicking the ▶️ icon in the top menu bar. This will run/execute the experiment via the python version installed in the standalone application.

To bring in some form of computing environment management, we have to set the Use PsychoPy version field in the Experiment Properties window -> please select 2023.2.3.

Testing the GUI dialog box#

If everything works/is set correctly, you should see a GUI dialog box appearing on your screen asking for the information we indicated in
our crtt_exp.py python script (chances are the layout on your end looks a bit different than mine, that’s no biggie).

After entering all requested information and clicking OK the GUI dialog box should close, a frame rate measurement should start and no errors should appear.

If you click Cancel the same thing should happen.

You can also check the logs via The runner

Wow, this actually works for everyone (hopefully)!

While this is kinda cool, it’s super detached from what we really wanted to do: exploring how we can run experiments using Python by building on top of all the things you already learned…

One way to still get something of that is to use PsychoPy’s builder magic …

Converting experiments to python code & scripts#

PsychoPy’s builder allows you to automatically convert experiments you build via the GUI to python code and scripts.

This is done via clicking the python icon in the top menu bar which should result in a new python script called crtt_exp.py
that opens in the editor window of The coder and is saved to your code/experiment folder.

But what’s in this python code? Let’s check it out in more detail and look for things we defined/set, as well as classic python aspects.

The builder components and routines - adding instructions#

After having set this crucial aspect of our experiment, it’s time to actually start it.

Quite often, experiments starts with several instruction messages that explain the experiment to the participant. Thus, we will add a few here as well, starting with a common “welcome” text message.

To display things in general but also text, the psychopy.visual module is the way to go. Regarding this we, however, need to talk about the general outline/functional principles of the builder first…

For example, if we want to add some instructions, we need to create a respective Routine.

To add one, click on “Insert Routine” and select “new” (should you already have an empty Routine, please make sure to delete it via right-clicking on it and selecting “remove”).

Finally, we’re going to give this new routine an informative name, ie “welcome”.

Within this routine, click on Text in the components window which should open a text properties window.

This allows to set basically everything we want/need regarding the message we want to display and once everything is set, click on OK and the presentation of the instruction is added to the Routine.

But what does all of this mean? Let’s have a closer look at the inputs and settings!

Now we need to add a Component to the Routine that will allow us to continue with the experiment once the space bar was pressed.

This is achieved via the Keyboard Component which will bring up the Keyboard Response Properties window. As with any other Components Properties window, we can set certain characteristics to attain a certain behavior.

Here, we set the Name of the Component, Start, Stop and that the Keyboard Response should end the Routine, i.e. allow us to continue to the next part of the experiment and specifically only via the allowed key “space”.

With that, our first ever routine is done and looks like this:

Testing the welcome routine#

Let’s give it a try via ▶️!

If everything works/is set correctly, you should see the GUI dialog box and after clicking OK, the text we defined as a welcome message should appear next and after pressing the space bar, the Experiment should end without any errors.

We are also going to update our python script again to check what changed via the python icon.

windows#

We came across one of PsychoPy’s core working principles: we need a general experiment window, i.e. a place we can display/present something on.

You can define a variety of different windows based on different screens/monitors which should, however, be adapted to the setup and experiment at hand (e.g., size, background color, etc.). You will get to the respective property window via the little screen icon next to the ⚙️ icon.

Basically, all experiments you will set up will require to define a general experiment window as without it, no visual stimuli (e.g. images, text, movies, etc.) can be displayed/presented or how PsychoPy would say it: drawn.

Speaking of which: this is the next core working principle we are going to see and explore is the difference between drawing something and showing it.

draw & flip#

In PsychoPy (and many other comparable software), there’s a big difference between drawing and showing something.

While we need to draw something on/in a window that alone won’t actually show it.

This is because PsychoPy internally uses “two screens” one background or buffer screen which is not seen (yet) and one front screen which is (currently) seen.

When you draw something it’s always going to be drawn on the background/buffer screen, thus “invisible” and you need to flip it to the front screen to be “visible”.

Let’s see how that looks in python code:

Why does PsychoPy (and other comparable software) work like that?

  • the idea/aim is always the same: increase performance and minimize delays
    (as addressed in the introduction)

  • drawing something might take a long time, depending on the stimulus at
    hand, but flipping something already drawn from the buffer to the
    front screen is fast(er)

  • can ensure better and more precise timing

  • can work comparably for images, sounds, movies, etc. where things are
    set/drawn/pre-loaded and presented exactly when needed

adding more instructions#

With these things set up, let’s add a few more messages to our experiment.

One will be presented right after the welcome message and explain very generally what will happen in the experiment.

Another one will be presented at the end of the experiment and display a general “that’s it, thanks for taking part” message.

The outline for creating, drawing and presenting these messages is identical to the one we just explored: we need to create respective Routines.

We’re going to start with some general instructions and information and add a new routine called instructions_general via Insert Routine -> (new).

After clicking OK, a white dot will appear which indicates where the new routine should be added.

Please make sure to add it after the welcome screen by moving the dot there and then clicking on it.

After that, the new routine should appear in our experiment and a respective new routine window

Task for y’all!

Now it’s time to add the actual general instructions. Please use above-outlined approach and components to do the following:

  • add this text: “In this task, you will make decisions as to which stimulus you have seen. There are three versions of the task. In the first, you have to decide which shape you have seen, in the second which image and the third which sound you’ve heard. Before each task, you will get set of specific instructions and short practice period. Please press the space bar to continue.”

  • add a component that advances the experiment, ie continues with the next screen, once participants pressed the space bar

If you get stuck, make sure to check the “welcome” routine again. You have 5 min and please let us know if you have questions/run into problems!

Answer

Step 1: Add a text component displaying the instructions

  • click on Text in the components window, set the stop to condition and remove any number in the respective value field

  • add the instructions in the Text window, adding some line breaks for readability

  • click OK

Step 2: Add a Keyboard response component that ends the routine

  • click on Keyboard in the components window, name it and remove any all but the ‘space’ key from the list of Allowed keys

  • click OK

Your new general instruction routine should now look something like this.

Task for y’all!

We also have to add the general end screen. Please use above-outlined approach and components to do the following:

  • add a new routine called end_screen

  • add this text: “You have reached the end of the experiment, thank you very much for participating. Please press the space bar to finish.”

  • add a component that ends the experiment once participants pressed the space bar

If you get stuck, make sure to check the “welcome” or prior routine again. You have 5 min and please let us know if you have questions/run into problems!

Answer

Step 1: Add a new routine

  • click on “Insert Routine” -> (new) and name it “end_screen”, placing it behind the instructions_general routine

Step 2: Add a text component displaying the message

  • click on Text in the components window, set the stop to condition and remove any number in the respective value field

  • add the instructions in the Text window, adding some line breaks for readability

  • click OK

Step 3: Add a Keyboard response component that ends the routine

  • click on Keyboard in the components window, name it and remove any all but the ‘space’ key from the list of Allowed keys

  • click OK

Your new end screen routine should now look something like this.

Task for y’all!

We still need to update our respective python script. Please use the convert to python functionality to convert our experiment again and thus update the corresponding python script. After that, please scroll through the python script to find and briefly evaluate the newly added routines and components.

If you get stuck, make sure to check the prior sections again. You have 5 min and please let us know if you have questions/run into problems!

Answer

Step 1: Convert the experiment to python

  • click on “Compile to Python script” and open/look the coder window

Step 2: Check the newly added routines and components

Testing the updated experiment#

Let’s give it a try via ▶️!

If everything works/is set correctly, you should see the GUI dialog box and after clicking OK, the text we defined as a welcome message should appear next, followed by the general instruction message and finally the end message.

Having this rough frame of our experiment it’s actually time to add the experiment itself: the “Choice Reaction Time Task”

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

PsychoPy#

stimuli & trials#

Quick reminder: our experiment should collect responses from participants regarding their perception of various stimuli: shapes, images and sounds.

Specifically, they should indicate which shape/image/sound was presented in a given trial via a dedicated button press.

Thus we need to add/implement three new aspects in our experiment: the presentation of stimuli, trials and responses.

We’re going to explain these concepts and their implementation based on the shape task.

adding further instructions - shape task#

At first, we need to add further instructions that are specific to the subsequent task as mentioned above, ie before each task (shape, image, sound), a short explanation should provide further information.

Adding a respective new routine and components is simply done as before.

Here are the instructions for copy-paste

In this task you will make a decision as to which shape you have seen.

Press C or click cross for a cross Press V or click square for a square Press B or click plus for a plus

First, we will have a quick practice.

Push space bar or click / touch one of the buttons to begin.

Your instructions for the shape task routine should now look something like this.

To support the familiarization with the task, we will also include some visual reminders concerning which button should be pressed when.

stimuli - the Image component#

To implement this, we need a new component: Image. Once you clicked on it, a window like the following should appear.

Comparable to the ones we’ve seen before, it allows us to specify important aspects of the Component and here specifically Image, ie visual stimulus.

There’s however something new: the Image field which allows us to set a path to the image we want to display.

The images and stimuli we want to use are actually part of the materials you downloaded, they can be found under school/materials/psychopy/stimuli.

At this point, we have to go back to RDM…

Following best practice RDM, where should the stimuli be stored?

They should be placed within the stimuli directory of our project/dataset directory.

choice_rtt/
    code/
    stimuli/

Please go ahead and move the shape stimuli to this directory.

choice_rtt/
    code/
    stimuli/
        shapes/
            ...

Now that we have the stimuli in place, we can set them in the Image Component. Importantly, we will create one image component per visual aid we want to display, ie three in total.

Starting with the first, we will select “response_square.jpg”

Given that we want to display multiple visual reminders and thus stimuli, we have to arrange and place them respectively in our window on the screen.

To achieve this, we can use the “Layout” tab of the Image component window, which let’s us set the Size and Position of the image at hand (among other things)

We are going to set (0.2, 0.1) for Size and (0, -0.25) for Position and leave the rest as is.

What python data type was used to set the size and position?

A tuple, denoting width and height concerning Size and x and y coordinates concerning position.

What do the other tabs entail?

Please have a quick look at the other tabs and briefly summarize what you can do with them.

While you’re at it, go back to the instruction message and change the Position under Layout to (0, 0.1) and the Letter Height under Formatting to 0.035.

Your updated shape task instruction routine should now look something like this.

Let’s give it a try via ▶️!

If everything works/is set correctly, you should see the visual reminder, ie image on the bottom of the window and the text should be smaller.

Fantastic! We will now add two more visual reminders for the other stimuli and set the following component properties:

  • Image component, stimulus: response_plus.jpg, Size: (0.2, 0.1), Position: (0.25, -0.25)

  • Image component, stimulus: response_cross.jpg, Size: (0.2, 0.1), Position: (-0.25, -0.25)

The remaining settings (e.g. duration, etc.) should be identical to the first Image component.

Your updated shape task instruction routine should now look something like this.

When running the experiment via ▶️ now, the instructions for the shape task should look something like this:

One thing we haven’t done in a while is to update our python script via the Compile Python script option and check the respective changes. Let’s do that!

If you scroll through the python script, you should be able to see the newly added images, ie visual stimuli:

implementing trials - shape task#

A lot of experiments, ie most of them, include a few task-specific practice trials and the experiment at hand is no exception to that. Especially considering that we have multiple sub-tasks. Thus, let’s add practice trials and while doing so, we are going to explore how to implement one core aspect of experiments in PsychoPy, trials.

(practice) trials#

Trials start like any other aspect of the experiment we’ve explored so far: by creating a new Routine. This one is going to be a bit special, though, as we want to utilize the same basic structure for practice and actual experiment trials, ie we will be using this routine at multiple points in our experiment.

The first point to do so, is right after the instructions_shape routine.

Starting easy, we will add the visual ques as we did before. However, instead of creating them from scratch, we will make use of the copy-paste functionality of components. In more detail, we will go back to the instructions_shape component, right-click on the component we want to copy, e.g. instruct_shape_square, select copy, go to the trial component, right-click, select paste and give the component a new name, e.g. visual_reminder_square.

Our newly created trial routine should now look something like this:

Task for y’all

Please apply the same approach to the other visual reminders, renaming them to visual_reminder_plus/cross respectively.

This is our trial routine after having added all visual reminders:

Great, that worked like a charm. Within the Choice Reaction Time Task, the to-be-evaluated/recognized stimulus can appear at different positions on the screen. Here, we are going with 4 different positions and thus will add 4 tiles at the respective position the stimuli can appear at/in. Concerning this, we will keep it simple and utilize a respective graphic called white_square.png and insert it as an Image at the desired positions. Thus, we need to add 4 new Image components to our trial routine.

The first one is going to be called “left_far_tile”, utilze the aforementiond white_square.png and be positioned at (-0.375, 0) with a size of (0.22, 0.22). Importantly, we will set its start to 0.5 so that it’s going to be presented shortly after the trial started.

Task for y’all

Please apply the same approach to the other tiles as follows:

  • name: left_mid_tile, position: (-0.125, 0)

  • name: right_mid_tile, position: (0.125, 0)

  • name: right_far_tile, position: (0.375, 0)

Your updated trial instruction routine should now look something like this.

Having set up the cues and tiles, we should start thinking about presenting the actual target, ie the stimulus participants have to evaluate and make decisions on. Obviously, we need another Image component and if you have a closer look at the stimuli directory, you’ll see a couple of files named target_. Given that 1+1=2, we know what to do: create a new Image component and set one of the target_ files as the image that should be presented. As it should appear slightly after the cues and tiles are already there, we will set its Start time to e.g. 0.7, present it for 0.2s (Stop duration (s)) and choose one of the tile position coordinates to present it at:

  • name: target_image

  • Start time(s): 0.7

  • Image: target_square.jpg

  • Size: (0.2, 0.2)

  • Position: (-0.125, 0)

Great job! Now, we only have to add a Keyboard Component to record the response of the participants. Comparable to the ones before, we set the Start time (s) to 0 and leave Stop duration (s) empty. In contrast to the Keyboard Components we set prior, we will change the Allowed keys to b,c,v with regard to the task and visual cues: b if a plus was presented, c if a cross and v if a square. This will also allow us to compute task performance, ie accuracies, later on.

That should do the trick. Let’s give it a try via ▶️.

You should now see the welcome message, followed by the general instructions, the task-specific instructions and then the first practice trial that remains on screen until you’ve responded via one of the set keys. Finally, you should see the end screen and the experiment should end without errors.

Looking back at our experiment flow, we can see, that we basically already got the core aspects implemented. Nice!

Wait: there’s a slight problem/inconvenience with this approach…but what?

While the approach worked nice for a single stimulus, we usually want to show lots of them and most likely different ones. So, do we have to set a new component for every single stimulus?

What would be a great way of utilizing a python control flow to adress this?

That’s right, we could use a for-loop to iterate over a list of stimuli, ie setting a new Image in the component with every trial iteration.

for-loops#

Implementing for-loops in PsychoPy is a three-stage endeavor (at least within the builder):

  • preparing a file that entails the list of stimuli we want to iterate over

  • creating/adapting a component to work iteratively

  • insert the for loop in the experiment flow

Stimuli lists#

While there are other ways to create stimuli lists (e.g. via coding, etc.), we will keep it brief and simple for this session and use a spreadsheet application to do so.

We only need to provide an informative column name, e.g. TargetImage and then provide the paths to the images below, one per row. An example is shown below: we will call the file shapes_targets.csv, define one column called TargetImage and then a list of stimuli, one per row. NB: you can use relative or absolute paths, just make sure that the path(s) is/are correct. Here, we used relative paths, pointing to the choice_rtt/stimuli/shapes directory relative to where the stimulus list is/will be saved, ie choice_rtt/code/experiment.

NB: If you don’t want to create this file, we also included it in the materials you downloaded, ie psychopy/choice_rtt/code/experiment. Just make sure to move it to the respective directory you saved the PsychoPy experiment in.

Using components iteratively#

With the stimuli list in place, we can continue with adapting our trial component to work iteratively.

Luckily, this is relatively straight-forward, as we “only” need to change the Image parameter of the component concerning two aspects:

  • instead of providing a path to one single stimulus, we will enter the name of the column that denotes the list of stimuli in our shapes_targets.csv, ie TargetImage, and add a $ in the beginning to indicate that the paths and thus stimuli provided in a given row should be used when iterating

  • instead of setting the presentation to constant, we will change it to set every repeat, ie indicating that we want to update the image every iteration of the for-loop

This approach is generally how creating/adapting components that work iteratively is done, e.g. also for other types of stimuli, etc. .

Inserting a for loop#

The last step entails adding the actual for loop. However, instead of adding it directly to the/a component, for loops are added “around” whatever is supposed to be “looped”, ie iteratively updated. In our example, the for loop should be added around the trial component.

Here’s how this is done:

  • click on “Insert Loop” in the Flow window

  • select the start position of the for loop by placing the dot before the routine that should be looped over

  • select the end position of the for loop by placing the dot after the routine that should be looped over

  • the for loop properties window should appear within which we can set the “behavior” of the for loop

  • we will set Name to PracticeLoop

  • we will set loopType to random, indicating that the stimuli list should be iterated over in a random fashion

  • we will set nReps to 1, indicating that the stimuli list should be iterated over once

  • we will set the Conditions file to be our shapes_targets.csv

If we did everything right, it should already state how many conditions and parameters are in our stimuli list. Here, it should be 6 conditions as we have 6 rows, ie stimuli and 1 parameter as we have one column, ie TargetImage.

After clicking OK, the for loop should be added to our experiment flow, enclosing the trial routine. This should look something like this.

Before we are going to try it…

What would be the expected behavior of our experiment?

  1. We see the welcome screen.

  2. We see the general instructions.

  3. We see the task-specific instructions.

  4. We get 6 practice trials across which the target is changed each iteration.

This seems that have worked out great. However …

What are the two other problems with the way we are presenting stimuli?

  1. We set a fixed onset, i.e., the target will always appear at the same time within the trial.

  2. We set a fixed position, i.e., the target will always appear at the same location within the window/on screen.

Both aspects are not ideal concerning fundamentals of experimentation (e.g. regarding fatigue and expectation, etc.) and are usually addressed via introducing a jitter so that the onset and position (in our example) are not constant but change between trials.

adding python code via Costum components#

While we could theorectically add more columns to our stimuli list file, ie jitter_onset and jitter_position, we will use this opportunity to explore another great feature of PsychoPy: adding python code via Costum components.

We already know that we can use the Builder to Compile a corresponding python script but we can also go the other way around and address some of the Builder’s limits (or just to be faster). The Costum component allows us to add python code that directly interacts with our routines and components. Here, we will use it to introduce jitters to the onset and position of the targets.

As with other components, we start by selecting it from the Components window, specifically Code.

This should open up the Code properties window, within which we set some properties and also enter our python code.

Initially, we are going to name it “jitterOnsetPosition” and select Begin Routine to indicate that the code should be run at the beginning of our routine, ie with each iteration of the for loop.

Now to the actual python code. What we need is:

  • a list of possible onsets called list_onsets

  • a list of possible positions called list_positions

  • picking one randomly for a given trial and assigning them to variables called onset_trial and position_trial

How would you implement this in python?

There are of course many different ways to do it, but here’s one.

#list of possible onsets for target
list_onsets = [1, 1.2, 1.4, 1.6, 1.8]

# randomize these onsets
shuffle(list_onsets)

#pick the first value from the list
onset_trial = list_onsets[0]

#list of possible positions for target
list_positions = [-0.375, -0.125, 0.125, 0.375]

# randomize these onsets
shuffle(list_positions)

#pick the first value from the list
position_trial = list_positions[0]

What other options can you think of?

With our python code ready, we simply copy-paste/write it in the left column of the Custom Code window.

After clicking OK, the component should appear in our routine.

So far, so good. However, to actally change the onset and position of the target at each iteration, we have to set this in the respective Image component properties, ie Start time (s) and Position [x,y].

In more detail, we have to replace the fixed values with the variables we’re assigning in our python code:

  • Start time (s) : onset_trial

  • Position [x,y]: (position_trial,0), set every repeat

As mentioned before, the python code and Builder directly interact with one another and thus are aware of the respective variables. In other words, at the beginning of every trial (routine) iteration, the python code will be run and generating the variables onset_trial and position_trial which are then used by the Image component to set the onset and position of the target, now in a jittered manner (based on the shuffle() in our python code.

One thing we need to do however, is to move the Custom Code component to the top of the components in order to ensure that it’s run first, ie generating the onset and position so that they can be used in the Image component.

We can do that via right-clicking on the Custom Code component and then select move to top.

When running the experiment via ▶️ now, the onset and position of the targets should change every trial.

providing participant feedback#

Another important aspect of practice trials is to provide participants with feedback concerning their performance to ensure that they understood the task and perform respectively. Here, we are going to provide feedback regarding their response accuracy and reaction time.

In order to do this in PsychoPy (at least our experiment), we need to do the following:

  1. add functionality to compute accuracy and reaction times on the fly

  2. add a new routine that presents the computed feedback

Starting with 1., we intially need adapt our Costum Code component jitterOnsetPosition and also indicate which response, ie button press is correct for a given image, so that we can utilize this information later on.

Here’s the python code we need to add:

#TargetImage is the variable in the Image field of the target_image component

#path of where to find the target image
if TargetImage == '../../stimuli/shapes/target_square.jpg': #path of where to find the target image

    #setting the key press that will be the correct answer
    corrAns = 'v'

#path of where to find the target image
elif TargetImage == '../../stimuli/shapes/target_cross.jpg':

    #setting the key press that will be the correct answer
    corrAns = 'c'

#path of where to find the target image
elif TargetImage == '../../stimuli/shapes/target_plus.jpg':

    #setting the key press that will be the correct answer
    corrAns = 'b'

Thus, our Custom Code Component should now look like this:

Given that we now have indicated what the correct response for a given stimulus would be, we can utilize this information within the keyboard_response component.

Under the Data tab we can actually set what the correct response or here Correct answer would be and if it should be stored. Here, we will set $corrAns and thus forward the information set in the Custom Code Component.

Additionally, we have to deselect the Save onset/offset times and Sync timing with screen fields in order to compute the respective reaction time.

Last but not least, we should change the Allowed keys field to set every repeat as we’re iterating over different stimuli.

This basically already assess if a response was correct by comparing the response to the set correct response of the respective stimulus. However, we still need to utilize this information and will do so by adding another Custom Code Component.

Within it, we will programmatically access the keyboard_response Component and its content. Let’s call it compRTandAcc and copy-paste/write the following python code in the tab End Routine to indicate that the code should be run at the end of the routine, ie each trial iteration.

#this code is to record the reaction times and accuracy of the trial

thisRoutineDuration = t # how long did this trial last

# keyboard_response.rt is the time with which a key was pressed
# thisRecRT - how long it took for participants to respond after onset of target_image
# thisAcc - whether or not the response was correct

# compute RT based on onset of target
thisRecRT = keyboard_response.rt - onset_trial

# check of the response was correct
if keyboard_response.corr == 1:

    # if it was correct, assign 'correct' value
    thisAcc = 'correct'

# if not, assign 'incorrect' value
else:
    thisAcc = 'incorrect'

# record the actual response times of each trial
thisExp.addData('trialRespTimes', thisRecRT)

As you can see, we directly access the keyboard_response Component, specifically keyboard_response.rt and keyboard_response.corr. While the latter entails the comparison between the response provided by the participant and the response we set as correct (ie if the correct key was pressed a 1 is assigned and if not a 0), the former entails the the reaction time in terms of the first key press within a given trial. Thus, we have to substract the onset_trial value from it to get the actual reaction time from target presentation to key press (Reminder: onset_trial is the variable assigned by the jitterOnsetPosition Custom Code Component.).

After clicking “OK”, the new Component should appear in the Routines window:

That concludes 1., let’s continue with 2.: add a new routine that presents the computed feedback.

At first, you’ve guessed it, we need to add a new routine via “Insert Routine” and we’re going to name it “practice_feedback” and place it behind the trial routine but still within the for loop as we want to present feedback after every practice trial.

As we want to present the feedback visually, ie via text, we will add a new Text Component and call it feedback_text. As with the other Text Components, we will set Start time (s) to 0.0 and leave Stop duration (s) empty.

The new functionality comes now: we have to once more interact with the Custom Code Component. This time, we need information from compRTandAcc, specifically the reaction time, ie thisRecRT, and accuracy, ie thisAcc.

We are going to use these variables within the Text field of the Component like so:

$"The last recorded RT was: "  + str(round(thisRecRT, 3)) + " \nThe response was: "  + thisAcc + " \n\nPress the space bar to continue."

In more detail, we’re making use of python strings and string formatting, via directly adding the variables to the string, ie text, that should be presented.

The leading $ in combination with setting the Text to set every repeat indicates that the variables and thus the string should be updated at each iteration, ie practice trial.

What are the \n denoting?

They are used to denote a line break.

The complete Text Component should look like this:

We will also add a Keyboard Component, calling it keyboard_response_feedback and setting the Allowed keys to 'space' in order to allow participant to advance to the next (practice) trial.

And that’s our routine to present the feedback computed by the compRTandAcc Custom Code Component.

If you now run the experiment again, you should be presented with a feedback screen after each practice trial, displaying your reaction time and if your response was correct.

To get the full experience, please make sure to go through the entire experiment once (we will also need the data in a few minutes)!

Great job everyone!

Now that we have collected our first set of responses, we can have a look at another core aspect of PsychoPy (and comparable software): storing and handling acquired data.

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

data output#

One thing we haven’t checked out yet is what kind of output, ie data is actually generated by PsychoPy and specifically, our experiment. Let’s start this topic with two quick questions.

Here’s the good news: PsychoPy is once again highly customizable and can provide many different types of output/data across many levels. As we didn’t set anything specific yet, we should start with having a look at the default output we get by running our (or any other) experiment.

default outputs#

By default, you should have a directory called data within the experiment direcotry within which all data acquired by running the experiment is stored.

choice_rtt/
    code/
        experiment/
            data/
                01_crtt_exp_2024-02-02.csv
                01_crtt_exp_2024-02-02.log
                01_crtt_exp_2024-02-02.psydat

As you can see, the file names should be a combination of the participant ID and the date (+ the time). Furthermore, there should be 3 different kinds of output/data files: .csv, .log and .psydat, each containing information about the experiment run at different level of detail. We will have a quick look at them now.

01_crtt_exp_2024-02-02.csv

The .csv file contains information, i.e. data, in a summarized way for each routine and trials therein, which is (kinda) intelligible and easy to grasp. Usually, this is the file you want to use/work with wrt to analyses, etc. .

While we definitely get a lot of data, its provided in way we can make sense of and easily utilize in subsequent steps: we get data concerning the presented routine (e.g. start/stop), trials (e.g. start/stop), stimuli (e.g. file, position in loop) and components (e.g. text, stimuli, responses) and we get the data entered in the GUI dialog box within the last columns. We also get the reaction time and accuracy we computed on the fly. Basically, everything we need.

01_crtt_exp_2024-02-02.log

The .log file contains information, i.e. data, in a detailed way for each and every frame, which is (kinda) intelligible but rather hard to grasp. Usually, these are the files you want to use/work with wrt to precise/detailed quality control and testing, etc. but not wrt analyses, etc. .

Here, we get each frame (left column), what “event type” happened during it (middle column) and what happend within the “event type” (right column).

01_crtt_exp_2024-02-02.psydat

The .psydat file as comparable to the .log as it contains information, i.e. data, in a detailed way for each and every frame. In order to view and interact with the data, you need to use PsychoPy’s python module.

At first, you need to load the data:

from psychopy.misc import fromFile

# set the psydat file
psydatFile = "/Users/peerherholz/Desktop/choice_rtt/code/experiment/data/01_crtt_exp_2024-02-01_09h33.45.473.psydat"

# load the psydat file
psydatFile_load = fromFile(psydatFile)

Which you can then view:

print(dir(psydatFile_load))

['__class__', '__del__', '__delattr__', '__dict__', '__dir__', '__doc__', '__eq__', '__format__', '__ge__', '__getattribute__', '__gt__', '__hash__', '__init__', '__init_subclass__', '__le__', '__lt__', '__module__', '__ne__', '__new__', '__reduce__', '__reduce_ex__', '__repr__', '__setattr__', '__sizeof__', '__str__', '__subclasshook__', '__weakref__', '_getAllParamNames', '_getExtraInfo', '_getLoopInfo', '_guessPriority', '_paramNamesSoFar', '_status', 'abort', 'addAnnotation', 'addData', 'addLoop', 'appendFiles', 'autoLog', 'close', 'columnPriority', 'currentLoop', 'dataFileName', 'dataNames', 'entries', 'extraInfo', 'getAllEntries', 'getJSON', 'getPriority', 'loopEnded', 'loops', 'loopsUnfinished', 'name', 'nextEntry', 'originPath', 'pause', 'resume', 'runtimeInfo', 'saveAsPickle', 'saveAsWideText', 'savePickle', 'saveWideText', 'setPriority', 'sortColumns', 'status', 'stop', 'thisEntry', 'timestampOnFlip', 'version']

or access/interact with:

trialHandler = psydatFile_load.loops[0]

trialHandlerParams = dir(psydatFile_load.loops[0])
print(trialHandlerParams)

print(trialHandler.data)
print(trialHandler.data['ran'])
print(trialHandler.data['order'])
print(trialHandler.data['keyboard_response_feedback.rt'])

['__class__', '__delattr__', '__dict__', '__dir__', '__doc__', '__eq__', '__format__', '__ge__', '__getattribute__', '__gt__', '__hash__', '__init__', '__init_subclass__', '__iter__', '__le__', '__lt__', '__module__', '__ne__', '__new__', '__next__', '__reduce__', '__reduce_ex__', '__repr__', '__setattr__', '__sizeof__', '__str__', '__subclasshook__', '__weakref__', '_createOutputArray', '_createOutputArrayData', '_createSequence', '_exp', '_makeIndices', '_terminate', 'addData', 'autoLog', 'data', 'extraInfo', 'finished', 'getCurrentTrial', 'getEarlierTrial', 'getExp', 'getFutureTrial', 'getOriginPathAndFile', 'method', 'nRemaining', 'nReps', 'nTotal', 'name', 'next', 'origin', 'originPath', 'printAsText', 'saveAsExcel', 'saveAsJson', 'saveAsPickle', 'saveAsText', 'saveAsWideText', 'seed', 'sequenceIndices', 'setExp', 'thisIndex', 'thisN', 'thisRepN', 'thisTrial', 'thisTrialN', 'trialList']
{'ran': masked_array(
  data=[[1.0],
        [1.0],
        [1.0],
        [1.0],
        [1.0],
        [1.0]],
  mask=[[False],
        [False],
        [False],
        [False],
        [False],
        [False]],
  fill_value=1e+20,
  dtype=float32), 'order': masked_array(
  data=[[1.0],
        [5.0],
        [4.0],
        [3.0],
        [0.0],
        [2.0]],
  mask=[[False],
        [False],
        [False],
        [False],
        [False],
        [False]],
  fill_value=1e+20,
  dtype=float32), 'keyboard_response.keys': array([['b'],
       ['c'],
       ['v'],
       ['c'],
       ['b'],
       ['c']], dtype=object), 'keyboard_response.corr': masked_array(
  data=[[1.0],
        [1.0],
        [1.0],
        [1.0],
        [1.0],
        [0.0]],
  mask=[[False],
        [False],
        [False],
        [False],
        [False],
        [False]],
  fill_value=1e+20,
  dtype=float32), 'keyboard_response.rt': masked_array(
  data=[[2.702897787094116],
        [2.077255964279175],
        [2.052070140838623],
        [2.1845827102661133],
        [2.8191428184509277],
        [2.8643736839294434]],
  mask=[[False],
        [False],
        [False],
        [False],
        [False],
        [False]],
  fill_value=1e+20,
  dtype=float32), 'keyboard_response.duration': array([[None],
       [None],
       [None],
       [None],
       [None],
       [None]], dtype=object), 'keyboard_response_feedback.keys': array([['space'],
       ['space'],
       ['space'],
       ['space'],
       ['space'],
       ['space']], dtype=object), 'keyboard_response_feedback.rt': masked_array(
  data=[[1.059588074684143],
        [0.6677191853523254],
        [0.7012380361557007],
        [0.6207000017166138],
        [2.571624517440796],
        [1.0015552043914795]],
  mask=[[False],
        [False],
        [False],
        [False],
        [False],
        [False]],
  fill_value=1e+20,
  dtype=float32), 'keyboard_response_feedback.duration': array([[None],
       [None],
       [None],
       [None],
       [None],
       [None]], dtype=object)}
[[1.0]
 [1.0]
 [1.0]
 [1.0]
 [1.0]
 [1.0]]
[[1.0]
 [5.0]
 [4.0]
 [3.0]
 [0.0]
 [2.0]]
[[1.059588074684143]
 [0.6677191853523254]
 [0.7012380361557007]
 [0.6207000017166138]
 [2.571624517440796]
 [1.0015552043914795]]

Which one you use further is definitely up to you, but starting with .csv is definitely a good default. While these three files are already pretty cool and useful, PsychoPy actually has quite a bunch more options concerning data output which we will explore next.

Output data properties#

One way to change the output data provided by PsychoPy, in terms of formatting, level of detail, etc., is to adjust the settings in the Data tab of the experiment Properties window which is accessible via the ⚙️ icon in the top menu bar.

Based on the settings we can see here, the generation of the output data files we checked before makes more sense:

  • the Data filename is created by using experiment variables (participant ID, experiment name and experiment date/time) and string formatting

  • the different output files are generated by Save log file, Save csv file (summaries) and Save psydat file

As you can see, we could actually set more properties, e.g. the Data file delimiter changing column arrangement, change the Logging level and save further output files, ie Save Excel file, Save csv file (trial-by-trial) and Save hdf5 file.

We can also add basically any data obtained via Costum Code Components as seen before:

# record the actual response times of each trial
thisExp.addData('trialRespTimes', thisRecRT)

For now, we will keep things as they are with one exception: the Data filename.

Changing data output files#

Going back to the RDM session and specifically Project and Data Organization, we learned utilizing a dedicated directory structure and file identifier will go a long way concerning FAIR-ness.

Obviously, we want to apply these principles to our experiment as well and therefore, we are going to change the Data filename in two aspects:

  • we will add the session identifier to the file name string

  • we will add a path variable to the file name so that we can choose a dedicated directory to save the data output files in

The first aspect is comparably easy and straightforward, as we already have the session identifier through our GUI dialog box and only need to add it to the file name string.

How would we do this?

We simply need to do the following:

u'data/%s_%s_%s_%s' % (expInfo['participant'], expInfo['session'], expName, expInfo['date'])

where expInfo['session'] is the value of the session field in our GUI dialog box.

The second aspect requires slightly more work, as we so far didn’t include an option to specify an output path. However, this is easily added to our GUI dialog box, via clicking the last + icon to add a field, which we will name “output-path”.

Following the same approach as above…

How would you add this to the file name?

We need to exchange the data string with the value of the output-path variable obtained from the GUI dialog box via `string formatting:

u'%s/%s_%s_%s_%s' % (expInfo['output-path'], expInfo['participant'], expInfo['session'], expName, expInfo['date'])

Fantastic, we’re almost there. One last thing we should think about and incorporate is the directory structure. As learned in the Project and Data Organization part of the RDM session, we should keep different versions of our data strictly separate to avoid confusion, data loss and provenance problems. Specifically, this refers to an example directory structure with the following aspects (applied to our experiment):

choice_rtt/
    code/
        experiment/
            crtt_exp.py
    stimuli/
        shapes/
    sourcedata/
        sub-ID
    sub-ID/
    derivatives/
        pipeline/
            sub-ID

Do you know what each aspect should entail?

Let’s have a look at the directories!

choice_rtt/

choice_rtt is our root directory within which we will store everything else, ie the highest level.

choice_rtt/
    code/
        expertiment/
            crtt_exp.py

Within code, we are going to store every piece of code related to the project/dataset. For example, code used to acquire data (as in our example the experiment directory, data conversion or data analyses.

choice_rtt/
    stimuli/
        shapes/

The stimuli directory will store all stimuli used during data acquisition, ie within the experiment.

choice_rtt/
    sourcedata/
        sub-ID

All acquired data in its “source” form, ie before conversion and/or standardization will be stored under sourcedata. Importantly, each participant will get their own directory in there.

choice_rtt/
    sub-ID/

raw data, ie data after conversion and standardization should be placed within a participant-specific directory, called sub-ID where ID is the participant identifier. All respective directories are stored directly at root.

choice_rtt/
    derivatives/
        pipelineID/
            sub-ID

The derivatives directory will store all derivatives obtained through applying some form of data processing to the raw data, ie in sub-ID. Within it, there should be one directory for each processing pipeline, e.g. preprocessing, statistics, etc. and within it usually one directory per participant in the form of sub-ID and/or group in case results are aggregated across participants.

Importantely, if you don’t have these directories yet, please make sure to create them via:

mkdir path/to/choice_rtt/sourcedata
mkdir path/to/choice_rtt/derivatives

Only adapting the string of the Data filename to

u'%s/sub-%s/ses-%s/%s_%s_%s_%s' % (expInfo['output-path'], expInfo['participant'], expInfo['session'], expInfo['participant'], expInfo['session'], expName, expInfo['date'])

unfortunately won’t be enough, as we have to make that the respective directories for a given participant and session are created before we attempt to save files there.

But no worries: we can just add Custom Code Component that does this for us. Let’s place at the beginning of the welcome routine so that it immediately creates the directory structure we need. Here’s the respective python code:

# Construct the path with placeholders replaced by actual values
dir_path = expInfo['output-path'] + "/sub-" + expInfo['participant'] + "/ses-" + expInfo['session']

# Check if the path exists
if not os.path.exists(dir_path):
    # Create the directory, including all intermediate directories
    os.makedirs(path)
    print(f"Directory '{dir_path}' was created.")
else:
    print(f"Directory '{dir_path}' already exists.")

How would you add this component to the welcome routine?

  • open the welcome routine

  • select the Custom Code Component

  • copy-paste/write the python code from above within the Begin Routine tab

  • click OK

With that in place, we adapt the Data filename string as indicated above:

u'%s/sub-%s/ses-%s/%s_%s_%s_%s' % (expInfo['output-path'], expInfo['participant'], expInfo['session'], expInfo['participant'], expInfo['session'], expName, expInfo['date'])

When running the experiment now, you should be able to specify a path in the GUI dialog box, which should be /path/to/choice_rtt/sourcedata, and the data output files should be stored under this directory in the aforementioned structure: /path/to/choice_rtt/sourcedata/sub-ID/ses-ID/.

Give it a try!

That seemed to have worked out great, awesome! This concludes our data output adventure and bring us to the next chapter.

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

A very simple experiment#

By now, we have already explored quite a lot of PsychoPy’s functionality, even though our experiment is quite simple. Speaking of which: we actually didn’t implement the experiment trials yet, only the practice ones.

In order to evaluate if we did a good job of teaching you the respective PsychoPy aspects and find potential gaps/problems, we kindly ask you to add the experiment trials to the experiment. Below you find a bit more information on how to do it, as well as the answer. However, it would be cool if you could give it an honest try first. After 30 min., we will go through the corresponding steps together.

Task 1 - Adding instructions for the actual trials

Similar to the instructions we provided for the practice trials, we should provide some for the actual trials. Thus, please add/do something to achieve the following:

  • the instructions should appear after the practice trials and before the actual trials

  • the following text should be displayed: “Well done, you have finished the practice! Now for the main experiment. Press space to continue!”

    • there should be line breaks between the sentences

  • participants should be able to end the instructions and start the experiment by pressing the space bar and only the space bar

Answer

Step 1: Copy-paste the instructions_shape Routine

  • the instructions_shape Component almost has all the things we need, except for the text which we can simply replace

  • select the instructions_shape Component in the Routine window

  • click on “Experiment” in the top menu bar and select Copy Routine

  • click on “Experiment” in the top menu bar and select Paste Routine

  • rename it, e.g. to “instructions_shape_experiment”

Step 2: Remove unnecessary Components

  • remove all Image Components via right-clicking on them and selecting “remove    “

Step 3: Adapt the Text

  • open the Text Component and exchange the Text to the one provided above, adding line breaks between sentences

  • optional: assign the Component a new name

Step 4: Insert the Component

  • select “Insert Routine” and choose instructions_shape_experiment

  • place it after the practice trial for loop and click on the dot

Done!

NB: While you also could have simply created a new Routine and add the respective Components, we wanted to show you the Copy-Paste Routine functionality. Here, it’s actually more work and takes longer, but for more complex and heavy Routines, this functionality comes in handy!

Great job, y’all! Let’s step it up with the next task.

Task 2 - Adding the actual trials

Now it’s time to add the actual experiment trials. Thus, please add/do something to achieve the following:

  • the experiment trials should appear after the experiment instructions and before the end screen

  • they should be identical to the practice trials in terms of cues, targets, keyboard responses, etc.

  • every stimulus in the stimuli list should appear 2 times

Answer

Given that the actual trials should be identical to the practice trials (in terms of their structure, etc.), we can simply make use of the trial Routine again and then add a new for loop.

Step 1: Re-use the trial Component

  • the trial Routine has all the things we need

  • click on Insert Routine and select trial

  • place it between the instructions_shape_experiment and end_screen Routine

  • click on the dot

Step 2: Add a for loop

  • click on Insert Loop

  • place the first dot before the just added trial Routine and the second on behind it

  • name it, e.g. to “exp_loop”

  • set nReps to 2

  • for Conditions select the stimuli list file, shapes_targets.csv

  • click OK


Done!

NB: As in Task 1, we could have created a new Routine from scratch but in this case re-using an already existing one was definitely faster.

Fantastic work everyone. However, there’s one last thing you need to do.

Task 3 - Run the experiment

After all this work, you should check what you have created and of course also test things. Thus, please go through the entire experiment at least once and afterwards have a look at the data!

That concludes our adventure into the basics of PsychoPy. While this was a lot already, we still wanted to talk about some advanced topics.

  • Running experiments (using python)

  • Introduction to PsychoPy

    • basic overview

    • basic working principles

  • PsychoPy

    • stimuli & trials

    • data output

    • a very simple experiment

  • PsychoPy advanced

    • Eye-Tracking and neuroimaging

    • online experiments

  • Outro/Q&A

PsychoPy advanced#

After exploring a lot of PsychoPy’s basic functionalities, we will also have a look at more advanced topics that are, however, common and important for everyday research work. Specifically, we will briefly talk about how to integrate Eye-Tracking, EEG and fMRI into PsychoPy, as well as have a look at running online studies based on PsychoPy.

ET, EEG and fMRI#

It should come to no surprise that PsychoPy supports the integartion of several external hardward very well. This includes:

  • Eye-Tracking

  • EEG

  • fMRI

  • microcontrollers, e.g. Arduinos

  • fNIRS

Within this brief exploration, we will focus on Eye-Tracking, EEG and fMRI.

Eye-Tracking#

PsychoPy has several options and functionalities to connect to and communicate with Eye-Tracking systems, directly via the Builder or the Coder.

Overall, adding Eye-Tracking to your PsychoPy experiment is a two-stage approach: Eye-Tracker setup/configuration, followed by integrating Eye-Tracking Components.

Setup/Configuration#

The setup and configuration of an Eye-Tracker is comparably easy and straightforward (We know, we know…we say this all the time.), as PsychoPy supports multiple common systems, including SR Research and Tobii Technology.

Initially, you need to access the Eye-Tracking tab of the experiment settings which you find via the ⚙️ icon in the top menu bar and select the device you’re using.

Depending on the device, you can then set a variety options and information such as the model and serial number of your device.

SR Research#

Please make sure to also have a look at the specific requirements outlined here.

Tobii Technology#

Please make sure to also have a look at the specific requirements outlined here.

MouseGaze#

Don’t have an Eye-Tracker ready to test wherever you’re working on your PsychoPy experiment and/or just want to simulate respective Eye-Tracking data? No worries at all, PsychoPy has your back.

You can select MouseGaze. This will allow your mouse cursor to act as a gaze point on your screen, and so allow you to simulate eye movements without using an Eye-Tracker. Then, when you’re ready to use your Eye-Tracker, you can just select it from the Experiment Settings and run your experiment in the same way.

Eye-Tracking Components#

PsychoPy comes with a core set of Component specifically for Eye-Tracking. You can find them in the Component window. In general, there are two types of Components: calibration/validation and recording.

Calibration/Validation#

When adding Eye-Tracking to your experiment, you usually want to start with adding the Calibration and Validation Component to the beginning of your experiment, ie the very first things that should happen.

Even though you select them from the Component window, they’re added as standalone Routines to your experiment.

You can then select and set different options for these Routines, e.g. the number of calibration points and their properties (e.g. color, size, etc.).

Recording - General#

To actually start recording Eye-Tracking data, you need to add the Eyetracker Record Component as this starts and stops the Eye-Tracker recording. Usually, you would add this Component to your instructions Routine or something similar, so that your Eye-Tracker is set off recording before your trials start, but you can add them in wherever makes sense for your experiment. As you can see below, you simply add it to the Routine during which you want to start/stop the Eye-Tracker.

Importantly, this Component does it all: start only, stop only and start and stop after a certain time.

Recording - ROIs#

If you want to record information on gaze position, or you want something to happen when the participant looks at or away from a certain part of the screen, the ROI Component is your best friend. The ROI Component has lots of options - you can choose what should happen given a certain gaze position/pattern, what shape the ROI has etc. All of which can also be defined in a conditions file (like we used for for loop), just like any other Component. Simply, choose the options that fit the needs of your experiment.

For our experiment, we could for example use the information, ie variables, generated in the Custom Code Component that jitters the onset and position of the target to indicate the ROI position and another Custom Code Component that interacts with the data generated by the ROI Component. In that way, the ROI Component behaves similarily to a visual Component, e.g. Image.

EEG#

Integrating EEG data acquisition in your PsychoPy experiment is no biggie either, although no dedicated Components exist. However, there are two important prerequisites and caveats you have address before you start.

Prerequisites and caveats#

At first, you have to think about problems inherent to EEG data acquisition in general, specifically timing and synchronization issues as outlined here.

Caveats#

We briefly talked about that at the beginning of this session, when we had a look at the Timing Mega Study by Bridges et al. 2020: there can be issues concerning dropped frames, lag and variability, monitor refresh rate (Poth at al., 2018) and so on.

In order to address these aspects and mitigate potential problems, it’s recommended to:

  • use the Builder as it automatically optimizes the code (e.g. draw and flip) concerning these problems

  • repeatedly test your experiment and evaluate timings

This is especially important for EEG where you have to work with millisecond precision.

Parallel & Serial Ports#

When connecting the machine you run your PsychoPy experiment on and the EEG system you’re using, you need to find out two aspects and set things in your experiment respectively:

  1. The port address your EEG acquisition system is connected to.

  2. How your EEG acquisition system wants to receive the triggers you send.

Why is this important? When acquiring EEG data via any software, including PsychoPy, you usually want to send triggers to the EEG system do denote what (e.g. conditions, stimuli) happened when (e.g. onset and duration), so that this information is added to the recorded data and available in the acquired EEG data.

Concerning 1., you have to find out if your setup is using a Parallel Port or a Serial Port. Then you can select the respective Component from the Component window, either within EEG or I/O and place it in the Routine you would like to add triggers to.

Each comes with a range of settings and options, such as

Insert a Serial Out component to the routine that you’d like to add triggers to

  • Start: when you want the trigger to be sent; this can be at a certain time or frame, or we can set the trigger to be sent when a certain condition is met (more on this later)

  • Stop: for how long the trigger should be sent

  • Port refers to the address of the port your device is connected to

  • Start data refers to the value that you want to actually send to your acquisition system - exactly what you’d like to send will depend on what your system wants to receive. This can take a variable just like most other fields so that you can send different triggers for different stimuli etc.

Both Components are essentially set up in the same manner, except that the Parallel port has the properties spread across tabs.

In case you have to add a port address, you can do so via Preferences -> Hardware:

Regarding 2., you have to carefully think about how you want to send triggers, ie as addressed before when and for how long, the trigger itself and so on.

As mentioned before, you usually want to set the Start to condition so that the trigger is send when something happens.

To send on the onset of something (e.g., a visual stimulus) set that condition to be (where stimulus is the name of the Component you want to yoke your trigger to, e.g. in our example TargetImage):

stimulus.status == STARTED

To send on a keypress, keep the Start as Condition and set the condition to be (where key_response is the name of your Keyboard Component):

key_response.keys

To send when a stimulus is clicked by a mouse (mouse here refers to the name of your mouse Component, and stimulus_mouse refers to the stimulus you want to be clicked):

mouse.isPressedIn(stimulus_mouse)

fMRI#

Generally, rather than programming your PsychoPy experiment to send triggers to some hardware in the same way as, e.g. EEG, with fMRI you would want to set up your experiment so that it waits until it has detected when the scanner has sent out a trigger before moving on to present trials.

Comparable to the other external hardware we talked about before, PsychoPy also allows you to run fMRI experiment and the respective implementation is done in a two-step-approach: the MRI scanner setup and trigger handling.

MRI scanner setup#

Before doing anything else, it’s important that you know how the scanner you’ll be using will emit these triggers, and whether these are converted to some other signal such as characters on a serial port or a simulated keypress. In general, there are at least 3 ways a scanner might send a trigger to your experiment:

  • emmulate a keypress

  • via parallel port

  • via serial port

Trigger handling#

A Routine to detect fMRI triggers is really simple to set up. Regardless of the method your scanner uses to send the triggers, you’ll just need a Routine that waits until it has detected the trigger before moving on.

A common approach is to create a new Routine and insert a Text Component that says “Waiting for Scanner”.

The scanner simulates a key press#

Insert a Keyboard Component to your "Waiting for Scanner" Routine. In allowed keys use the key that the scanner will send e.g. if the scanner sends a 5, the allowed keys will be 5.

Now, when the keypress is detected, the "Waiting for Scanner" screen will end and the next Routine, e.g. trials start. Although, be careful! PsychoPy doesn’t know the difference between the emulated key presses sent from the scanner and key presses made by a participant! So take care not to type on the keyboard connected to the PsychoPy computer whilst your experiment runs to avoid your key presses being mistaken for triggers.

The scanner communicates via a port#

Regardless if serial or parallel port, you want to add a Custom Code Component to set up the respective port and check for triggers.

In the Begin Experiment tab of the Code Component, add the following code to set up a Parallel Port:

from psychopy.hardware.parallel import ParallelPort
triggers = ParallelPort(address = 0x0378) #Change this address to match the address of the Parallel Port that the device is connected to
pinNumber = 4 #Change to match the pin that is receiving the pulse value sent by your scanner. Set this to None to scan all pins

and for a Serial Port:

from psychopy.hardware.serial import SerialPort
triggers = SerialPort('COM3', baudrate = 9600) #Change to match the address of your Serial Port
trigger = '1' #Change to match the expected character sent from your scanner, or set to None for any character

In the Each Frame tab of the same Code Component, add the following code to check for triggers.

For a Parallel Port:

if frameN > 1: #To allow the 'Waiting for Scanner' screen to display
    trig = triggers.waitTriggers(triggers = [pinNumber], direction = 1, maxWait = 30)
    if trig is not None:
        continueRoutine = False #A trigger was detected, so move on

and for a Serial Port:

if thisTrigger in self.read(self.inWaiting()):
    continueRoutine = False #Our trigger was detected, so move on

Lastly, you have to make sure that your experiment keeps in synch with the MRI scanner to avoid timing issues. In more detail, if you only synch the experiment and the MRI scanner in the beginning of the experiment, their timescales might get out of synch as the experiment progresses. Thus, it’s a good idea to add a synchronization to certain parts of the experiment, e.g. when a block of trials is over, etc. . This can basically be implemented via the approach described above.

Running experiments online - PsychoPy & Pavlovia#

After our brief tour of communicating with and integrating external hardware, we will also have a brief look at running PsychoPy experiments online via its connection to Pavlovia.

Pavlovia#

Pavlovia is a secure server for running experiments and storing data. It’s built upon a git-based version control system and has a huge open-access library of experiments (that you can add to!). Additionally, it’s place for creating and running Surveys (using Pavlovia Surveys).

Account & costs#

In order to get started, you only need to create a free account using your institutional (or other) Email address. Afterwards, you can immediately start using Pavlovia, e.g. uploading your PsychoPy experiment or creating a survey.

While the account itself is free, acquiring data is not. However, with only ~ 0.28 Cents to store one participant’s data, it’s comparably cheap (e.g. acquiring data from 1000 participants would be less than 300 Euro).

Regarding this, you need to buy Pavlovia Credits through the Pavlovia Store.

Experiments library and dashboard#

As mentioned before, Pavlovia has a huge open-access library of experiments that you can browse, re-use and adapt. Furthermore, it allows you to query the library concerning certain properties.

Your experiments are stored in the dashboard which has the same interface as the open-access library. You can of course choose if your experiment should be public or private.

Launching an experiment#

Pavlovia evolved from the PsychoPy realm and those the two have a direct connection that you can leverage to launch the experiment, you created locally via PsychoPy, online via Pavlovia.

When you make an experiment in PsychoPy’s Builder, your experiment can compile to python (for running offline) or JavaScript (which allows it to run in a browser). Pavlovia acts as the way of hosting the JavaScript file online (it handles creating a URL for you to share with your participant, saving the data etc.).

Initially, you have to make sure your files are set up such that you have one directory that only contains one .psyexp file and the files needed to run the experiment. For example, in our experiment we have:

choice_rtt/
    code/
        experiment/
            crtt_exp.psyexp
            crtt_exp.py
            shapes_targets.csv

Which means, that we almost have everything ready to go. We would only need to add the stimuli filesso that they’re included as well.

After that’s done, we have to open the experiment in the Builder and log into Pavlovia.

You can now sync your experiment to Pavlovia:

Select project info then select the hyperlink, that will take you to your Pavlovia project (if you are not logged into Pavlovia.org already in the browser you may need to log in to view).

You can then set your experiment to running and given you have Pavlovia credits, you start acquriring data by sharing the link to the experiment with your participants.

Once your participant completes the experiment, you can view data in one of two ways. Either select "Download Results" or "View Code" to see all the data in the "data" subfolder of your project.

Integration with recruitment platforms#

Sometimes you might want to connect your experiment with other platforms. For example, you might use a third party service to help with recruitment (such as prolific or SONA). In these cases you want your experiment to go through something like the following chain:

  • recruitment website: participants discover your experiment and are issued a participant ID

  • experiment and/or survey: participant completes the experiment and/or survey

  • recruitment website: mark as complete so participants can be reimbursed if needed

and you want information like “participant ID” as well as other info to be passed forward through the chain.

How does this work?

Information is passed to a website using something known as a query string. This is essentially any information that follows a “?” in the URL in your browser. For example, your experiment could have the URL:

run.pavlovia.org/your_user_name/your_experiment_name/

This would likely start up your experiment with a dialogue window where you can type participant and session. You could however provide the respective values already within the URL using a query string, like this:

run.pavlovia.org/your_user_name/your_experiment_name/?participant=123&session=1

Here the last part of the URL is a query string, and you will notice that this autocompletes the fields “participant” and “session” in the startup dialogue of your experiment. This is what happens when you daisy chain with other platforms, platform 1 will send information via a query string to platform 2, then platform 2 sends it to platform 3 and so on…

The exact implementation, however, depends on the recruitment platform you are using.

Git-based features#

By now, you might have already noticed that Pavlovia exists on Gitlab. As we have learned in the Git & Gitlab session, it’s pretty feature rich and allows many neat features and control over your projects:

Version control: view the version history of your experiment and restore old versions

Collaboration: Add team members or fork projects to groups

Privacy settings: Make your project public or private

You can access the Gitlab repository of your project by selecting “View code” on your project dashboard.

Contents
